Silbloxx 3D configurator

Configure your silos

1 2 3

How does the Silbloxx 3D configurator works?

View the animation on the right
Configure your silos in a few clicks
Download a 3D model (.stp)
Create an account and manage your configurations or edit them at a later time
Send a request for quotation for your configuration

Name your configuration *

Choose a standard configuration

Nederlands Français Deutsch

Aantal rijen Aantal kolommen

Choose the configuration for

silo 1

A custom quote?

You can contact our sales for this at +32 (0)51 54 12 63 or info@silbloxx.com.

Or fill out a contact form by clicking here and we'll contact you as soon as possible to explore the possibilities together.

Bin Walls Bin Top Hopper

Storage of *

Steel grade *

Stainless steel (304)

Will be finished with spray pickling.

Carbon steel (S235/S355)

Can be finished with a powder coating, wet coating or can be hot dip galvanized.

Silo width (mm) *

The silo width is the distance from the center silo column to the center next silo column.

Where a wall is shared with another silo, the width of both silos must be the same.

Exceptional sizes are configurable in a custom quote.

Silo length (mm) *

The silo length is the distance from the center silo column to the center next silo column.

Where a wall is shared with another silo, the length of both silos must be the same.

Exceptional sizes are configurable in a custom quote.

Silo height (mm) *

The silo height is the distance between the bottom of the bottom layer of silo panels and the top of the top layer of silo panels.

Exceptional sizes are configurable in a custom quote.

Height compared to the reference plane (mm)

Bin wall *

Smooth wall

Features

flat
double-walled
smooth flow of bulk goods
for products that normally do not flow easily, such as flour, corn, feed, ...
can not be hot dip galvanized

Corrugated wall

Features

profiled
single-walled
light in weight
for products that flow easily such as coffee, cocoa, rice, ...

Sliding/bolted column

Sliding

Bolted

Treatment inside silo *

High-quality epoxy powder coating
foodgrade for dry bulk goods as a long-term protective coating for an indoor installation (corrosion class C2 interior (L) according to standard NBN EN ISO 12944)

High-quality epoxy wet paint
foodgrade for dry bulk goods as a temporary protective layer for indoor installation.

Quality zinc coating
as a long term protective coating for an indoor or outdoor installation according to standard NBN EN ISO 1461:2009)

Necessary cleaning procedure
for contaminations of stainless steel after processing (lasering, welding, ...) (according to standard NBN EN 2516:1997)

Any other type of treatment, color or combination of treatments is configurable in a custom quote.

Treatment outside silo *

High-quality epoxy wet paint
foodgrade for dry bulk goods as a temporary protective layer for indoor installation.

Quality zinc coating
as a long term protective coating for an indoor or outdoor installation according to standard NBN EN ISO 1461:2009)

Necessary cleaning procedure
for contaminations of stainless steel after processing (lasering, welding, ...) (according to standard NBN EN 2516:1997)

Any other type of treatment, color or combination of treatments is configurable in a custom quote.

Volume (m³)

Water volume (m³)

Weight (kg)

Options

Electrolytic galvanized bolts

Hot dip galvanized bolts

Stainless steel bolts

Supporting structure

A supporting steel structure can also be provided by Silbloxx. This is configurable in a custom quote.

Delivery

Transportation can also be provided by Silbloxx. This is configurable in a custom quote.

Installation

Installation can also be provided by Silbloxx. This is configurable in a custom quote.

Vertical rounded corners (VHAW)

With our clever 'VHAW' system, you can create rounded corners in a smooth wall silo for products that move difficultly in order to ensure a perfect flow.

Internal noses on the walls

This 'nose' welded to our silo walls reliefs pressure on the walls due to heavy products ensuring a good flow and to avoid the product would jam or form layers.

Low level detector socket (hopper)

Inlet type

Inlet x coordinate (mm)

Inlet y coordinate (mm)

Manhole

Treatment inside of inlet

High-quality epoxy wet paint
foodgrade for dry bulk goods as a temporary protective layer for indoor installation.

Quality zinc coating
as a long term protective coating for an indoor or outdoor installation according to standard NBN EN ISO 1461:2009)

Necessary cleaning procedure
for contaminations of stainless steel after processing (lasering, welding, ...) (according to standard NBN EN 2516:1997)

Any other type of treatment, color or combination of treatments is configurable in a custom quote.

Treatment outside of inlet

High-quality epoxy wet paint
foodgrade for dry bulk goods as a temporary protective layer for indoor installation.

Quality zinc coating
as a long term protective coating for an indoor or outdoor installation according to standard NBN EN ISO 1461:2009)

Necessary cleaning procedure
for contaminations of stainless steel after processing (lasering, welding, ...) (according to standard NBN EN 2516:1997)

Any other type of treatment, color or combination of treatments is configurable in a custom quote.

Options

ATEX

Silbloxx silos can meet ATEX requirements to be used in explosive environments. ATEX silos are configurable in a custom quote.

High level detector socket

High level detector sunken

Silo outlet/hopper *

Square-rectangular

Features

for smooth wall & corrugated wall
centric outlet at a 60° angle
equipped with connection for a low level detector

All kinds of options/specials such as eccentric outlet, manholes or additional connections are configurable in a custom quote.

Round

Features

only for smooth wall
centric outlet at a 70° angle
equipped with connection for a low level detector
with patented corner finish (so called 'butterfly hoppers') for a perfect flow

All kinds of options/specials such as eccentric outlet, manholes or additional connections are configurable in a custom quote.

You can contact our sales team for this at +32 (0)51 54 12 63 or info@silbloxx.com. Or fill in a contact form by clicking here and we will contact you as soon as possible to look at the possibilities together

Hopper x coordinate (mm)

Hopper y coordinate (mm)

Outlet width (mm)

Outlet length (mm)

Hopper height (mm)

Hopper angle (°)

Treatment inside of hopper

High-quality epoxy wetpaint
foodgrade for dry bulk goods as a temporary protective layer for indoor installation.

Treatment outside of hopper

High-quality epoxy wetpaint
foodgrade for dry bulk goods as a temporary protective layer for indoor installation.

Options

Acces hatch

An access hatchs allows you to enter and inspect the hopper and (standard dimensions 600x400 mm)

Empty detector

Looking glass

Impactor plate

This reinforcement of the hopper allows locally hard knocking without damaging the hopper plate in case of need.

Pressure relief cone

This cone welded to our silo hoppers reliefs pressure on the hopper outlet for products with heavy pressure.

Poke hole

This hole in the hopper allows you to poke in the product inside the hopper in case of need

Round flange

Round opening in bin top with flange to connect silo accessories/machines

Square flange

Round opening in bin top with flange to connect silo accessories/machines
